model	CL-SF5702
Overall dimensions	W1175*L575*H250
Filter size	Filter size Clean class 100 @0.3um (Federal Standard)
The rated air flow	1050m3/h±20%
Maximum air volume	1800m3/h±20%
Average wind speed	0.45-0.70m/s±20% (wind speed adjustable)
Filtration efficiency	99.99%＠0.3um-99.99999%＠0.12um《可選》
The noise	46-53db±3db
The noise test	Filter below 1 meter test
The power supply	220V 50HZ
The material	The box body is imported aluminized zinc plate/cold rolled steel rod baking paint /SUS stainless steel/aluminum plate

The 100-grade FFU laminar flow hood has the advantages of long working time, low noise, maintenance free, small vibration, stepless speed regulation, uniform wind speed, easy installation, etc.

One hundred grade FFU laminar flow hood can be modularized and connected to use, making FFU widely used in clean room, clean operation table, clean production line, assembled clean room and local 100 grade applications.

One hundred stage FFU laminar flow hood features:

1.FFU external size (mm) : 1175*575*320, beautiful appearance

2. Hundred grade FFU laminar flow enclosure and high efficiency filter adopts split design, installation, replacement is efficient and convenient;

3. The 100th grade FFU laminar flow cover fan adopts Singapore PCI direct drive centrifugal fan, and the working time is more than 100,000 hours;

4. Hand-level FFU with energy saving, computer centralized control, stable operation, low noise, digital adjustment and other characteristics;

5. Class 100 FFU adopts a unique air duct with uniform wind speed, and the whole air outlet surface is uniformly delivered at 0.45m/s-0.75m/s wind speed.

6. The 100 grade FFU shell can be made of mirror stainless steel, aluminized zinc plate and cold plate by electrostatic spray.

FFU before factory according to the United States federal standard (209E) with laser particle counter scanning detection, to ensure quality;

FFU is suitable for 10~100000 level dust-free workshop, convenient for centralized control of the overall operation;

FFU is ideal for large area use. With unique advantages and reasonable prices quickly occupy the market.
